Colors
A DCOF value of > 0.42 is the new standard for tiles specified for commercial application in standard A137.1-2012, Section 9.6. It replaces the SCOF value of
> 0.60 referenced in ASTM C1028. For more information on the correlation between the two values and about the DCOF AcuTest visit the Tile Council of
North America's website:
www.tcnatile.com
MANUFACTURER'S WARNING:
- Tiles with DCOF Acutest values less than .42 are not recommended for use in areas with wet or slippery conditions. If such tiles are used as a walking
surface where water, ice, oil, great and/or other substances are present, such a condition could cause a reduction in foot traction and become unexpectedly
slippery resulting in a fall and personal injury. See ANSI standard A137.1 section 6.2.2.1.10, available at www.tcnatile.com/sections6.2.2.1.10.html.
- Water, oil, grease, etc. create slippery conditions. Floor applications with exposure to these conditions require extra caution in product selection. Not for
use on ramps.
- For additional information, refer to Factors to Consider.
- Since there is a shade variation on all natural products, the tile and trim supplied for your particular installation may not match these samples. Final
selection should be made from actual tiles and trim and not from tile and trim samples or color reproductions. Manufactured in accordance with ANSI
A137.1 standards.
Benefits
*colors 100 & 200
Style Number
TGJ88
TGJ89
TGJ90
TGJ91
TGJ92
Construction
ceramic
ceramic
ceramic
ceramic
ceramic
Tile Type
floor tile
floor tile
floor tile
bullnose
mosaic
Tile Size
13" x 13"
17" x 17"
12" x 24"
2.75" x 13"
13" x 13" x 2"
Technical
Wear Rating Group
4*, 3
4*, 3
4*, 3
NA
4*, 3
Break Strength
350
350
350
NA
350
Water Absorption
3-6%
3-6%
3-6%
3-6%
3-6%
DCOF
> 0.42
> 0.42
> 0.42
> 0.42
> 0.42
Shade Variation
V3
V3
V3
V3
V3
200 Beige
200 Beige
570 Dark Grey
570 Dark Grey
100 Bone
100 Bone
500 Light Grey
500 Light Grey
13" x 13" x 2" Mosaic
TGJ92
