Colors
A DCOF value of > 0.42 is the new standard for tiles specified for commercial application in standard A137.1-2012, Section 9.6. It replaces the SCOF value of
> 0.60 referenced in ASTM C1028. For more information on the correlation between the two values and about the DCOF AcuTest visit the Tile Council of
North America's website:
www.tcnatile.com
MANUFACTURER'S WARNING:
- Tiles with DCOF Acutest values less than .42 are not recommended for use in areas with wet or slippery conditions. If such tiles are used as a walking
surface where water, ice, oil, great and/or other substances are present, such a condition could cause a reduction in foot traction and become unexpectedly
slippery resulting in a fall and personal injury. See ANSI standard A137.1 section 6.2.2.1.10, available at www.tcnatile.com/sections6.2.2.1.10.html.
- Water, oil, grease, etc. create slippery conditions. Floor applications with exposure to these conditions require extra caution in product selection. Not for
use on ramps.
- For additional information, refer to Factors to Consider.
- Since there is a shade variation on all natural products, the tile and trim supplied for your particular installation may not match these samples. Final
selection should be made from actual tiles and trim and not from tile and trim samples or color reproductions. Manufactured in accordance with ANSI
A137.1 standards.
Benefits
*color 700 only
Style Number
TGL71
TGL70
TGL72
TGL73
TGL74
Construction
ceramic
ceramic
ceramic
ceramic
ceramic
Tile Type
floor tile
floor tile
floor tile
bullnose
mosaic
Tile Size
18" x 18"
13" x 13"
6" x 6"
2.75" x 13"
13" x 13" x 2"
Technical
Wear Rating Group
3* & 4
3* & 4
3* & 4
3* & 4
3* & 4
Break Strength
250 lbs
250 lbs
250 lbs
250 lbs
250 lbs
Water Absorption
3-6%
3-6%
3-6%
3-6%
3-6%
DCOF
< 0.5
< 0.5
< 0.5
< 0.5
< 0.5
Shade Variation
V2
V2
V2
V2
V2
220 Canyon
220 Canyon
600 Torchwood
600 Torchwood
*700 Foothills
*700 Foothills
200 Sandstone
200 Sandstone
350 Reservior
350 Reservior
13" x 13" x 2" Mosaic
CS92Q
